Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner

Name: Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner
Brand: Dengwanyi Co., Ltd
SKU: HDPE LDPE LLDPE
Price: 0.30 USD
Availability: InStock

Brand Name:	SZ
Model Number:	HDPE LDPE LLDPE
MOQ:	30000 square meters
Price:	$0.3-$2.0/SQM
Payment Terms:	T/T,L/C
Supply Ability:	100 Tons per day

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO

Product Name:

Anti-seepage ASTM HDPE Geomembrane

Thickness:

100Mil 2.5mm

Application:

Wastewater Treatment Plant

Function:

Anti-seepage Waterproof

Material:

HDPE LDPE LLDPE

Type:

Smooth Or Textured

Length:

50m-200m

Width:

1m-8m

Packaging Details:

Packed in woven bag or your requirements

Supply Ability:

100 Tons per day

Highlight:

astm hdpe geomembrane

hdpe geomembrane 100mil

astm hdpe textured geomembrane

Product Description

Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner

Yixing Shenzhou HDPE Geomembrane

1.Main Thickness:0.2mm,0.3mm,0.5mm, 0.75mm,1.0mm,1.5mm,2.0mm,3.0mm,4.0mm,5.0mm
2.Main Width:4m, 5m, 5.8m, 6.0m, 7m, 8m,10m
3.Main Length:50m/100m/150m/200m
4.Main Color: black, white, blue, green
5. Optional surface: Textured or Smooth surface.
6.Material:HDPE, LDPE,LLDPE,EVA
7. Certificate & Test: ISO, TRI, SGS
8. Quality Control: Third party test and factory lab test

Yixing Shenzhou HDPE Geomembrane For Wastewater Treatment Plant

1. Primary/Secondary Containment
Anaerobic digesters
Aeration tanks
Sludge thickening ponds

2. Specialized Structures
Effluent storage lagoons
Biosolid drying beds
Odor control covers

3. Safety Systems
Emergency overflow ponds
Stormwater retention basins
Leachate collection pads

Yixing Shenzhou HDPE Geomembrane for Sewage Treatment Advantage

Our HDPE geomembranes provide absolute liquid containment for urban sewage treatment facilities, preventing groundwater contamination while withstanding aggressive wastewater environments. The smooth surface facilitates sludge removal and maintenance.

Wastewater Treatment Plant ASTM HDPE Geomembrane 100Mil Waterproof Membrana Pond Liner 0

Waterproof HDPE Geomembrane Sewage-Specific Installation Protocol

Subgrade Preparation
- 95% Proctor compaction
- Geotextile protection layer (300g/m² recommended)
Welding Requirements
- Dual-track hot wedge seams
- 100% seam testing (spark/vacuum)
Anchoring System
- Termination trenches with polymer anchors
- Overflow pipe penetrations with boot details

No.	Properties	Test Method	Test Value
1	Thickness(mm)	ASTM D5199	0.50	0.75	1.00	1.25	1.50	2.00	2.50	3.00
2	Density (g/cm2)	ASTM D1505	0.939
3	Tensile Propeties
	Yield Strength(N/mm)	ASTM D6693	7	11	15	18	22	29	37	44
	Break Strength(N/mm)	ASTM D6693	13	20	27	33	40	53	67	80
	Yield Elongation %	Type IV	12
	Break Elongation %	Type IV	700
4	Tear Resistance/N	ASTM D1004	62	93	125	156	187	249	311	374
5	Puncture Resistance/N	ASTM D4833	160	240	320	400	480	640	800	960
6	Stress Crack resistance/hr	ASTM D5397 (App.)	300
7	Carbon Black
	Carbon Black Content %	ASTM D1603	2.0-3.0
	Carbon Black Dispersion	ASTM D5596	Carbon black dispersion(only near spherical agglomerates)for 10 different views 9 in categories 1 or 2 and 1 in category 3
8	Oxidative Induction Time(OIT)
	Standard OIT/min	ASTM D3895	100
	High Pressure OIT/min	ASTM D5885	400
9	Oven Aging at 85°C
	Standard OIT-% retained after 90 days	ASTM D3895	55
	High pressure OIT-% retained after 90 days	ASTM D5885	80
10	UV Resistance
	Standard OIT retained after 1600 hrs	ASTM D3895	50
	High pressure OIT retained after 1600 hrs	ASTM D5885	50
11	Low tempreture impact brittle property at -70°C	_	Pass
12	Permeability g·cm/(cm2)·Pa	_	≤1.0×10-13
13	Dimensional Stability/%	_	±2
