Asphalt Coated Fiberglass Geogrid 50 50 Highways Expressways Reinforce Asphalt Surfaces Reduce Cracking

Brand Name:	SZ
Model Number:	FG
MOQ:	10,000 Square Meter
Price:	$0.3-$2.0/SQM
Payment Terms:	L/C,T/T
Supply Ability:	100,000 Square Meters per Week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO,CE

Product Name:

Asphalt Coated Fiberglass Geogrid 50 50

Application:

Highways Expressways

Function:

Reinforce Asphalt Surfaces Reduce Cracking

Material:

Fiberglass Yarn

Coating:

Bitumen & Asphalt Geogrid

Tensile Strength:

50kN/m-300kN/m

Elongation Rate:

<=4%

Width:

1-6m

Length:

50m-100m

Mesh Size:

25.4*25.4mm 12.5*12.5 50.8*50.8

Packaging Details:

By roll, paper pipe + black PE shrinkage membrane + woven bag ( waterproof & UV resistance)

Supply Ability:

100,000 Square Meters per Week

Product Description

Asphalt Coated Fiberglass Geogrid 50 50 Highways Expressways Reinforce Asphalt Surfaces Reduce Cracking

Why Choose Shenzhou Geosynthetics Asphalt-Coated Fiberglass Geogrid?

✅ Proven Performance – Used in major infrastructure projects worldwide
✅ Reduces Maintenance Costs – Minimizes cracks and potholes
✅ Fast & Efficient Installation – Compatible with standard paving equipment
✅ Customizable Options – Available in different strengths and sizes

Fiberglass Geogrid Function:

high temperature resistance (mostly used in the construction of asphalt pavement), function

1. Effective reinforcement and anti-cracking, effectively prolonging the life of the road

(asphalt pavement, cement concrete pavement subgrade reinforcement)

2. It has high tensile strength and low elongation in both directions of warp and weft, and has excellent properties

such as high temperature resistance, low cold resistance, aging resistance, and corrosion resistance.

3. Slow down cracking

Asphalt Coated Fiberglass Geogrid 50 50 Highways Expressways Reinforce Asphalt Surfaces Reduce Cracking 0

Fiberglass Geogrid Specification

Fiberglass geogrid technological standard(GB/T 21825-2008)
specification		FG30×30	FG50×50	FG 60×60	FG 80×80	FG 100×100	FG 120×120	FG 150×150
Mesh center distance(mm)	MD	25.4±3.8 , 12.7±3.8
Mesh center distance(mm)	CMD	25.4±3.8 , 12.7±3.8
breaking strength(kn/m)	MD	30	50	60	80	100	120	150
breaking strength(kn/m)	CMD	30	50	60	80	100	120	150
Breaking Elongation(%)	MD	4	4	4	4	4	4	4
Breaking Elongation(%)	CMD	4	4	4	4	4	4	4
Width(m)		1m-6m	1m-6m	1m-6m	1m-6m	1m-6m	1m-6m	1m-6m

Asphalt Coated Fiberglass Geogrid 50 50 Highways Expressways Reinforce Asphalt Surfaces Reduce Cracking 2

Before Coated Bitumen After Coated Bitumen

Asphalt Coated Fiberglass Geogrid 50 50 Highways Expressways Reinforce Asphalt Surfaces Reduce Cracking 3

Mesh Size 25.4x25.4mm Mesh Size 12.8x 12.8 mm

Key Benefits:
✔ Optimal Load Distribution – Reduces stress and prevents reflective cracking
✔ Asphalt-Compatible – Bitumen-coated for superior adhesion in paving applications
✔ High Tensile Strength – 50 kN/m in both directions (longitudinal & transverse)
✔ Corrosion & UV Resistant – Long-lasting durability in harsh conditions
✔ Easy Installation – Flexible, lightweight, and roll-form for quick deployment

Primary Applications:
