20Mil HDPE Geomembrane Lining Corrosion Resistant For Fish / Shrimp Ponds

Name: 20Mil HDPE Geomembrane Lining Corrosion Resistant For Fish / Shrimp Ponds
Brand: Shenzhou Earth Working Material Co. Ltd
SKU: HDPE LDPE LLDPE
Price: 0.30 USD
Availability: InStock

Brand Name:	SZ
Model Number:	HDPE LDPE LLDPE
MOQ:	30000 square meters
Price:	$0.3-$2.0/SQM
Payment Terms:	T/T,L/C
Supply Ability:	100 Tons per day

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO

Product Name:

20mil ASTM HDPE Geomembrane

Thickness:

20MIL

Application:

Fish / Shrimp Ponds

Function:

Corrosion Resistance

Material:

HDPE LDPE LLDPE

Type:

Smooth Or Textured

Length:

50m-100m

Width:

1m-8m

Packaging Details:

Packed in woven bag or your requirements

Supply Ability:

100 Tons per day

Highlight:

20mil HDPE geomembrane pond liner

corrosion resistant geomembrane for ponds

HDPE geomembrane for shrimp ponds

Product Description

20Mil HDPE Geomembrane Lining Corrosion Resistant For Fish / Shrimp Ponds

Yixing Shenzhou HDPE Geomembrane For Fish / Shrimp Ponds

HDPE geomembrane is a reliable, durable, and cost-effective lining solution for anti-seepage and waterproofing. Its combination of impermeability, strength, and chemical resistance makes it an essential material for environmental protection, water conservation, mining, petrochemical, and agricultural projects worldwide.

Applications of HDPE Geomembrane

Geomembranes find extensive use in water containment systems, such as reservoirs, ponds, and canals. By acting as impermeable liners, they help conserve and manage water resources, prevent seepage, and maintain water quality. In addition to water containment, geomembranes serve as effective tools in erosion control, stabilizing slopes, and protecting shorelines from degradation due to wave action and erosion.

20Mil HDPE Geomembrane Lining Corrosion Resistant For Fish / Shrimp Ponds 0

How to Use HDPE Geomembrane?

1.Site Preparation

Clear the area of sharp objects, roots, stones, or debris that could puncture the liner.

Level and compact the subgrade to provide a smooth surface.

If needed, place a geotextile cushion layer beneath the geomembrane for extra protection.

2.Liner Deployment

Unroll the HDPE geomembrane carefully on the prepared surface.

Avoid dragging the liner to prevent scratches or tears.

Allow the sheets to relax and fit naturally to the ground surface.

3.Seaming / Welding

Overlap adjacent sheets (usually 10–15 cm).

Use hot wedge welding or extrusion welding machines to fuse seams.

Ensure seams are strong, watertight, and tested for leaks.

4.Inspection & Testing

Perform non-destructive tests (air channel test, vacuum test, or spark test) to check seam quality.

Repair any defects immediately.

5.Anchoring & Covering

Anchor the geomembrane edges into trenches or fix with ballast to prevent movement.

If required, cover with soil, sand, gravel, or concrete for UV protection and stability.

Practical Tips

Install during calm weather (avoid strong winds).

Keep the geomembrane clean and dry before welding.

Only trained technicians should operate welding equipment.

Store rolls in a shaded area to prevent UV damage before use.

ASTM Standard, GRI GM13 HDPE Geomembrane Specification:

Properties	Test method	GM075	GM100	GM125	GM150	GM200	GM250	GM300
Thickness	D5199	0.75mm	1.00mm	1.25mm	1.50mm	2.00mm	2.50mm	3.00mm
Density	D1505	0.940	0.940	0.940	0.940	0.940	0.940	0.940
Tensile properties 1. Yield strength 2. Breaks strength 3. Yield elongation 4. Break elongation	D6693 Type IV	11KN/m 20KN/m 12% 700%	15KN/m 27KN/m 12% 700%	18KN/m 33KN/m 12% 700%	22KN/m 40KN/m 12% 700%	29KN/m 53KN/m 12% 700%	37KN/m 67KN/m 12% 700%	44 KN/m 80 KN/m 12% 700%
Tear resistance	D1004	93N	152N	156N	187N	249N	311N	374N
Puncture resistance	D4833	240N	320N	400N	480N	640N	800N	960N
Stress crack resistance	D5397(App.)	300hr	300hr	300hr	300hr	300hr	300hr	300hr
Carbon black content	D1603	2.0%	2.0%	2.0%	2.0%	2.0%	2.0%	2.0%
Oxidative induction time (OIT)	D3895	100 min	100min	100min	100 min	100min	100min	100min
