Warp-Knitting Biaxial Uniaxial Polyester Reinforced Geogrid For Reinforcing Pavement Concrete Road

Warp-Knitting Biaxial Uniaxial Polyester Reinforced Geogrid For Reinforcing Pavement Concrete Road

Brand Name:	SZ
Model Number:	PET
MOQ:	10.000 m2
Price:	$0.3-$2.0/SQM
Payment Terms:	T/T,L/C
Supply Ability:	30.000 SQM PER DAY

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Product Name:

Polyester Geogrid

Application:

Reinforcing Pavement Concrete Road

Usage:

Stabilizing Foundation Slope Road Construction

Tensile Strength:

120-120

Mesh Size:

25.4x25.4mm / 50.8x50.8mm

Roll With:

1-6M

Package:

By Roll With Woven Bags

Process:

Woven Coated Warp Knitted

Packaging Details:

Packed in double layer woven bags to ensure smooth arrival and avoid rough handle.

Supply Ability:

30.000 SQM PER DAY

Highlight:

120-120KN polyester geogrid mesh

soil reinforcement geogrid for embankments

retaining wall geogrid for slopes

Product Description

Warp-Knitting Biaxial Uniaxial Polyester Reinforced Geogrid for Reinforcing Pavement Concrete Road

Main Application Areas

Highway and railway subgrade reinforcement: Improves subgrade bearing capacity and extends road surface life.
Slope protection: Prevents soil slippage on slopes.
Embankments and revetments: Enhances soil-rock structure stability.
Airport runways and parking lots: Improves foundation strength.
Mine and tunnel support: Used as a reinforcement material for supporting structures.

Warp-Knitting Biaxial Uniaxial Polyester Reinforced Geogrid For Reinforcing Pavement Concrete Road 0

PET Polyester Geogrid Advantages

High Strength, Low Elongation → Ensures Stabilit
Chemical and Aging Resistance → Long Service Life
Easy Construction → Reduces Project Costs
Excellent Adhesion to Soil → Improves Reinforcement

Warp-Knitting Biaxial Uniaxial Polyester Reinforced Geogrid For Reinforcing Pavement Concrete Road 1

Polyester Geogrid vs. Fiberglass Geogrid Comparison Table

Warp-Knitting Biaxial Uniaxial Polyester Reinforced Geogrid For Reinforcing Pavement Concrete Road 2

Comparison Items	Polyester Geogrid	Fiberglass Geogrid
Raw Materials	High-strength polyester filament (PET)	Glass Fiber (E-glass)
Production Process	Warp knitting/braiding → Heat setting → Coating (PVC, SBR, etc.)	Warp Knitting/Knitting → Coating (Asphalt or PVC)
Tensile Strength Range	20–800 kN/m, wide strength range	30–200 kN/m, commonly used for low to medium strength applications
Elongation	Low (approximately 8–12%), with some ductility	Very low (approximately 2–5%), almost no elongation
Aging Resistance	Excellent resistance to acids, alkalis, corrosion, and durability	Relatively poor, sensitive to alkaline environments, prone to aging
Temperature Adaptability	-40°C to +60°C	-100°C to +200°C (higher heat resistance than polyester)
Weight	Lightweight, easy to transport and lay	Also lightweight, but the fiber is more brittle
Price	Slightly higher (depending on raw materials and process)	Relatively inexpensive
Main Applications	- Highway and railway subgrade reinforcement	- Asphalt pavement reinforcement
Service life	Long life (10–20 years or more, depending on working conditions)	Medium (5–10 years, requires good maintenance)
Adhesion	Good adhesion between the coating and the soil/asphalt	Excellent adhesion to asphalt (commonly used in asphalt pavement)

✅ Brief Summary:
Polyester geogrid → Suitable for geotechnical engineering and long-term load-bearing reinforcement (roadbeds, slopes, and embankments).
Fiberglass geogrid → More suitable for pavement maintenance and crack prevention (especially asphalt pavement reinforcement).
