Polyester Geogrid
Created with Pixso.

Environmentally Friendly Polyester Geogrid for Sustainable Construction Projects

Environmentally Friendly Polyester Geogrid for Sustainable Construction Projects

Brand Name: SZ
Model Number: PET
MOQ: 10.000 m2
Price: $0.3-$2.0/SQM
Payment Terms: T/T,L/C
Supply Ability: 30.000 SQM PER DAY
Detail Information
Place of Origin:
CHINA
Certification:
CE
Product Name:
Biaxial BX Polyester Geogrids
Tensile Strength:
50-1200 KN/M
Application:
Sustainable Construction Project
Usage:
Reinforce Retaining Walls Providing Stability
Mesh Size:
25.4x25.4mm / 50.8x50.8mm
Roll With:
1-6M
Package:
By Roll With Woven Bags
Process:
Woven Coated Warp Knitted Coated PVC Or SBR
Packaging Details:
Packed in double layer woven bags to ensure smooth arrival and avoid rough handle.
Supply Ability:
30.000 SQM PER DAY
Highlight:

BX polyester geogrid for retaining walls

,

reinforced polyester geogrid for roads

,

polyester geogrid for pavement stabilization

Product Description

Environmentally Friendly Polyester Geogrid for Sustainable Construction Projects



Product Range
Products are the representation of a corporate entity, which determine its image and popularity amongst the buyers. Keeping this significant aspect in mind, we deliver purely cost-effective and genuine products with an impressive preservation factor. In a nutshell, we are a leading and an eminent manufacturer and exporter of the category of products, enumerated below

  • Plastic Geogrid ( Biaxial / Uniaxial / Triax / Hexagon )
  • Warp knitted Fiberglass geogrid coated with bitumen
  • Warp knitted woven coated polyester geogrid
  • Non Woven Geotextile with PET and PP material. With staple fibre and filament process
  • HDPE / LDPE / LLDPE Geomembrane
  • Geocomposited Geogrid / Geocomposited membrane
  • GCL
  • Custimized product

Environmentally Friendly Polyester Geogrid for Sustainable Construction Projects 0Environmentally Friendly Polyester Geogrid for Sustainable Construction Projects 1

Specification of POLYESTER GEOGRID

Spec
PETU
55-30
PETU
60-30
PETU
80-30
PETU
100-30
PETU
120-30
PETU
150-30
PETU
200-30
PETU
300-30
Tensile strength
≥(kN/m)
warp
55
60
80
100
120
150
200
300
weft
30
30
30
30
30
30
30
30
Elongation≤(%)
13 or 10
Grid size(mm)
25.4x25.4 or 50.8x50.8 or 76.2x76.2
Width(m)
2 or 2.5 or 3.95 or 5.0 or 5.2 or 5.95
NOTES: Other tensile strength can be made: 400-50, 500-50, 600-100, 700-100, 800-100 etc.

Polyester Geogrid Feature and Applications

Features
Applications
•High Tear Strength
•Soil Stabilization
•Flexible and durable
•Subgrade impovement
•Excellent Creep Resistance
•Earth Embankments over piles
•UV resistance / Cost effective
•Landfill, Bridging of voids and sinkholes
•High chemical and biological resistance
•Retaining Retaining Walls / Steep Slopes
•High Tensile Strength and Low Elgongation
•Road, Runways or Pavement construction
•Optimun stability of the junction strength of the grid

•Increased pull-out resistance and compound strength

•High resistance to installation damage and ease of installation




Reinforcing the Future of Infrastructure

Strong, durable, and cost-effective polyester geogrids engineered to stabilize soil, strengthen foundations, and extend the lifespan of your projects.

Environmentally Friendly Polyester Geogrid for Sustainable Construction Projects 2

Environmentally Friendly Polyester Geogrid for Sustainable Construction Projects 3Environmentally Friendly Polyester Geogrid for Sustainable Construction Projects 4

FAQ

1. who are we?
We are based in Jiangsu Province, China, start from 2004,sell to South Asia(5.00%),Southeast Asia(15.00%),Southern Europe(2.00%),Eastern Europe(2.00%),North America(5.00%),Central America(5.00%),Northern Europe(3.00%),Africa(2.00%),Mid East(1.00%)Domestic Market(60.00%). There are total about 200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
HDPE Geomembrane / Geotextile / Geogrid / GCL / Geocomposites and so on.


4. why should you buy from us not from other suppliers?
With a 80.000 m2 facility and more than 40 production lines, we enable faster lead times and stable production, ensuring you always have stock ready to meet market demand. We have fully automotive plants with best quality as Per client.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,GBP,CNY,CHF;
Accepted Payment Type: L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union;
Language Spoken:English
