PVC Or SBR Coated UX Reinforced Polyester Geogrid Steep Slopes Reinforcement

PVC Or SBR Coated UX Reinforced Polyester Geogrid Steep Slopes Reinforcement

Brand Name:	SZ
Model Number:	PET
MOQ:	10.000 m2
Price:	$0.3-$2.0/SQM
Payment Terms:	T/T,L/C
Supply Ability:	30.000 SQM PER DAY

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Product Name:

UX Reinforce Polyester Geogrid

Tensile Strength:

50-1200KN/M

Application:

Steep Slopes Reinforcement

Usage:

Stabilize The Soil

Mesh Size:

25.4x25.4mm / 50.8x50.8mm

Roll With:

1-5m

Package:

By Roll With Woven Bags

Coating:

PVC Or SBR

Packaging Details:

Packed in double layer woven bags to ensure smooth arrival and avoid rough handle.

Supply Ability:

30.000 SQM PER DAY

Highlight:

PVC coated polyester geogrid

SBR reinforced geogrid for retaining walls

5.2x100M polyester geogrid stabilizer

Product Description

PVC Or SBR Coated UX Reinforced Polyester Geogrid Steep Slopes Reinforcement

Geogrid is a geosynthetic material made of polymer, used to reinforce the soil behind the retaining wall.

The geogrid is installed in the horizontal layer between the wall layers and extends into the soil behind the wall to stabilize the soil, thereby increasing the quality and stability of the wall system. The geogrid reinforced filling structure uses TT geogrid, which is made by extrusion and unidirectional stretching of high-density polyethylene. The high demand for geogrid and its application in construction is due to its good tensile strength and higher performance.

PVC Or SBR Coated UX Reinforced Polyester Geogrid Steep Slopes Reinforcement 0

Polyester Biaxial Geogrid

Specification		PET 15-15	PET 20-20	PET 25-25	PET 30-30	PET 40-40	PET 50-50	PET 60-60	PET 80-80
Tensile strength (KN/M)	Vertical	15	20	25	30	40	50	60	80
Tensile strength (KN/M)	Horizontal	15	20	25	30	40	50	60	80
Specification		PET 100-100	PET 120-120	PET 200-200	PET 300-300	PET 400-400	PET 600-600	PET 800-800	PET 1200-1200
Tensile strength (KN/M)	Vertical	100	120	200	300	400	600	800	1200
Tensile strength (KN/M)	Horizontal	100	120	200	300	400	600	800	1200
Elongation(%)		≤13
Width(m)		1-6
Mesh size(mm)		12.712.7, 25.425.4, 50.850.8, 76.276.2

Polyester uniaxial geogrid

Specification		PET 35-20	PET 35-30	PET 55-20	PET 55-30	PET 60-30	PET 80-30	PET 100-30	PET 120-30
Tensile strength (KN/M)	Vertical	35	35	55	55	60	80	100	120
Tensile strength (KN/M)	Horizontal	20	30	20	30	30	30	30	30
Specification		PET 150 -30	PET 200 -30	PET 300 -30	PET 400-30	PET 600 -50	PET 600-400	PET 1000 -50	PET 1200-100
Tensile strength (KN/M)	Vertical	150	200	300	400	600	600	1000	1200
Tensile strength (KN/M)	Horizontal	30	30	30	30	50	400	50	100
Elongation(%)		≤13
Width(m)		1-6
Mesh size(mm)		12.712.7, 25.425.4, 50.850.8, 76.276.

Uniaxial Polyester Geogrids Applications:
Commonly used in retaining walls, slopes, embankments, and other applications where soil reinforcement is needed.
PVC Coating:
Many uniaxial geogrids are coated with PVC, which provides additional chemical, mechanical, and UV protection.

PVC Or SBR Coated UX Reinforced Polyester Geogrid Steep Slopes Reinforcement 1

PVC Or SBR Coated UX Reinforced Polyester Geogrid Steep Slopes Reinforcement 2

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

For more expertise and solutions For Uniaxial Reinforce Polyester Geogrids,

please contact Yixing Shenzhou !
