Anti UV Filtration Separation Reinforce 200g/sqm Polyester Nonwoven Geotextile Fabric Parking Lots And Driveways

Anti UV Filtration Separation Reinforce 200g/sqm Polyester Nonwoven Geotextile Fabric Parking Lots And  Driveways

Professional-grade 200gsm polyester nonwoven geotextile.

Yixing Shenzhou Geosynthetics Perfect for soil separation, stabilization, and drainage

in demanding civil and construction projects.

Weight: Common weights range from 100 gsm to 400 gsm

(e.g., 100, 150, 200, 250, 300, 350, 400 g/m²), with 300 gsm being

 a popular choice for heavy-duty applications.

Roll Dimensions: Typically supplied in rolls of 2.0m to 6.0m wide and 50m to 100m long.

Custom sizes are often available.

Yixing Shenzhou Geosynthetics Polyester Geotextile Function :

Separation: Prevents the intermixing of two distinct soil layers (e.g., preventing the subsoil

from mixing with a gravel base course in road construction), which maintains the structural integrity and load-bearing capacity of the overlying material.

Filtration: Allows for cross-plane water flow while preventing the loss of fine soil particles,

effectively controlling erosion and siltation.

Protection: Acts as a cushioning layer to protect delicate geomembranes (like HDPE liners in landfills)

from puncture by sharp aggregates or subgrade irregularities.

Drainage: Provides a plane for water to move along, facilitating lateral drainage and

reducing hydrostatic pressure behind retaining walls or in drainage systems.

          Nonwoven Geotextile Production process        &         Nomwoven Geotextile production line

Yixing Shenzhou Geosynthetics Polyester Nonwoven Geotextile Product Features:

Heavy-Duty Protection: 300 grams per square meter provides robust puncture resistance

and superior load distribution.

High Tensile Strength: Made from 100% polyester, offering excellent mechanical properties

 and long-term performance under stress.

 Optimal Permeability: Excellent water flow (permittivity) prevents waterlogging and ensures

proper drainage, preserving soil integrity.

UV & Rot Resistant: Chemically inert and resistant to biological degradation, ensuring

 performance for the long haul.

 Environmentally Durable: Withstands pH variations in soil, making it suitable for a wide

range of ground conditions.

100-800g/sqm Polyester Nonwoven Geotextile Technical Specifications

Yixing Shenzhou 200g/sqm Polyester Nonwoven Geotextile Project Applications

Road and Railway Construction:

Used under railballast, subgrades, and base courses for separation and stabilization.

Landfill and Erosion Control:

Used in landfill liner systems, leachate collection layers, silt fences, and slope revetment under riprap.

Drainage Systems:

Wrapped around French drains, aggregate drains, and drainage pipes to

act as a filter fabric.

Retaining Walls:

Installed behind walls for drainage and to prevent backfill soil from washing away.

Parking Lots and Pavements:

Placed beneath asphalt paving or under aggregate for patios and driveways to extend service life.

Frequently Asked Questions (FAQ)

Q: Is this fabric woven or nonwoven?
A: This is a nonwoven, needle-punched geotextile. This structure gives it excellent filtration and separation properties, unlike woven fabrics which are primarily for reinforcement.

Q: Why choose polyester over polypropylene?
A: Polyester generally offers higher tensile strength at a given weight and better resistance to creep

(elongation under long-term load), making it ideal for high-stress stabilization projects.

Q: How does the 200g/sqm weight compare to others?A: 200gsm is a medium-to-heavy weight geotextile.

 It's significantly stronger and more durable than lighter weights (e.g., 100-200gsm) and is chosen for

 permanent, critical applications.

Q: Can I use this under a residential driveway?
A: Absolutely. While it's professional-grade, it's an excellent choice for a residential driveway that

will bear heavy vehicle traffic, ensuring it remains level and crack-free for years.

Q: Do you offer custom roll sizes?
A: Yes. While our standard rolls are 4/5/5.8x 50m, we can customize the width and length to suit large-scale project requirements.

Yixing Shenzhou Geosynthetics 300g/m² Short Fiber Polyester Nonwoven Geotextile
