Brand Name: | SZ |
Model Number: | HDPE LDPE LLDPE |
MOQ: | 30000 square meters |
Price: | $0.3-$2.0/SQM |
Payment Terms: | T/T,L/C |
Supply Ability: | 100 Tons per day |
Yixing Shenzhou HDPE Geomembrane
HDPE geomembrane liner is the preferred product for lining projects. HDPE liner is resistant to many different solvents and are the most widely used geomembrane liner in the world. Although HDPE geomembrane is less flexible than LLDPE, it provides higher specific strength and can withstand higher temperatures. Its exceptional chemical and ultraviolet resistance properties make it an extremely cost-effective product
Properties | Unit | Test Method | Product Specification | Test Frequency |
Thickness | mm | ASTMD5199 | 0.2-3 | Per roll |
Density | g/cc | ASTMD1505/D792 | 0.94 | 90,000kg |
Asperity Height | mm | ASTMD 7466 | 0.4 | every 2nd roll |
Applications of HDPE
Specification of HDPE
No. | Properties | Test Method | Test Value | |||||||
1 | Thickness(mm) | ASTM D5199 | 0.50 | 0.75 | 1.00 | 1.25 | 1.50 | 2.00 | 2.50 | 3.00 |
2 | Density (g/cm2) | ASTM D1505 | 0.939 | |||||||
3 | Tensile Propeties | |||||||||
Yield Strength(N/mm) | ASTM D6693 | 7 | 11 | 15 | 18 | 22 | 29 | 37 | 44 | |
Break Strength(N/mm) | 13 | 20 | 27 | 33 | 40 | 53 | 67 | 80 | ||
Yield Elongation % | Type IV | 12 | ||||||||
Break Elongation % | 700 | |||||||||
4 | Tear Resistance/N | ASTM D1004 | 62 | 93 | 125 | 156 | 187 | 249 | 311 | 374 |
5 | Puncture Resistance/N | ASTM D4833 | 160 | 240 | 320 | 400 | 480 | 640 | 800 | 960 |
6 | Stress Crack resistance/hr |
ASTM D5397 (App.) |
300 | |||||||
7 | Carbon Black | |||||||||
Carbon Black Content % | ASTM D1603 | 2.0-3.0 | ||||||||
Carbon Black Dispersion | ASTM D5596 |
Carbon black dispersion(only near spherical agglomerates)for 10 different views 9 in categories 1 or 2 and 1 in category 3 |
||||||||
8 | Oxidative Induction Time(OIT) | |||||||||
Standard OIT/min | ASTM D3895 | 100 | ||||||||
High Pressure OIT/min | ASTM D5885 | 400 | ||||||||
9 | Oven Aging at 85°C | |||||||||
Standard OIT-% retained after 90 days | ASTM D3895 | 55 | ||||||||
High pressure OIT-% retained after 90 days | ASTM D5885 | 80 | ||||||||
10 | UV Resistance | |||||||||
Standard OIT retained after 1600 hrs | ASTM D3895 | 50 | ||||||||
High pressure OIT retained after 1600 hrs | ASTM D5885 | 50 | ||||||||
11 | Low tempreture impact brittle property at -70°C | _ | Pass | |||||||
12 | Permeability g·cm/(cm2)·Pa | _ | ≤1.0×10-13 | |||||||
13 | Dimensional Stability/% | _ | ±2 |
Product standards and purchase recommendations of HDPE
·. Implementation standards: National standard GB/T17643-2011, Urban Construction CJ/T234-2006, some scenes need to meet the American standard GRI-GM13.
· Purchase points: Select thickness (0.2-3.0mm) and surface type (glossy/rough) according to project requirements, and give priority to raw material products to improve durability.
HDPE geomembrane has become an irreplaceable environmentally friendly material in modern engineering due to its excellent impermeability, weather resistance and mechanical strength. In practical applications, it is necessary to select specifications based on project requirements and strictly follow construction specifications to ensure long-term stability.
FAQ:
Q: What is a geomembrane used for?
A: HDPE geomembrane is suitable for environmental protection, sanitation, water conservancy engineering, municipal engineering, garden, petrochemical, mining, agriculture, aquaculture, salt industry, hydraulic, transportation, and oil and gas applications as well as in the waste industry.
Q: What are the three types of geomembranes?
A: Geomembrane, as a kind of geosynthetics, is mainly divided into HDPE Geomembrane(high density polyethylene geomembrane) or HDPE liner, LLDPE Geomembrane(line low density polyethylene geomembrane) and PVC Geomembrane(Polyvinyl Chloride Geomembrane).
Q: What are the HDPE geomembrane liners?
A: HDPE geomembrane liners – High-Density Polyethylene geomembrane liners.
Q: What are the types of geomembrane sheets?
A: In terms of material, geomembrane types are divided into HDPE geomembrane sheets and LLDPE geomembrane sheets. In terms of color, geomembrane types are divided into black geomembrane, blue geomembrane, green geomembrane, and white geomembrane. In terms of usage, geomembrane types are divided into aquaculture geomembrane and engineering geomembrane. From the surface, the geomembrane types are divided into smooth geomembrane and rough geomembrane. There are many types of geomembranes, but the main function is to provide support for seepage prevention and environmental protection. Our company is a geomembrane liner company and factory, we can customize geomembrane according to customer needs.
Q: What is the thickness of the geomembrane?
A: Geomembrane Thickness range 0.3mm-3mm.
Q: What is the best thickness for a geomembrane pond liner?
A:0.75mm geomembrane thickness is popular.
Q: Is Geomembrane HDPE waterproof?
A: Yes, our HDPE Geomembrane is a waterproof Geomembrane, impermeable Geomembrane.
Q: How long will the geomembrane pond liner last?
A:> 10 years exposed to the sun.
Q: Why is the geomembrane pond liner black?
A: The carbon black can improve the UV resistance, and life is longer.
Q: How do I know how much geomembrane pond liner I need?
A: The geomembrane width and geomembrane length, geomembrane depth, geomembrane overlap, extra length for trench, and the geomembrane waste rate.
Q: How do choose suitable geomembrane manufacturers from China?
A: YIXING SHENZHOU geomembrane liner, factory price, ASTM standard quality, delivery time within 15 days, Top 10 geomembrane manufacturers, and suppliers from China.
