Antiseepage Reinforce reservoir dikes banks 2mm 80mil   HDPE Geomembrane Liner For Water conservancy

Water conservancy Industry Composite Liner System (Top to Bottom):

• • Protection Layer: 30cm graded gravel/concrete blocks (scour resistance)

  • Cushion Layer: 400g/m² needle-punched geotextile (puncture protection)

  • Anti-Seepage Layer: HDPE geomembrane (staggered seams ≥500mm)

  • Support Layer: Compacted clay (≥93% compaction, CBR ≥5%)

Yixing Shenzhou HDPE Geomembrane  Key Advantages:

Industrial Strength: Withstands heavy equipment and sharp substrates

Versatile Performance: -60°C to +80°C operational range

Custom Sizes: Up to 8m wide × 100m long panels

Third-Party Tested: Include certified test reports

Yixing Shenzhou HDPE Geomembrane

1.Main Thickness:0.2mm,0.3mm,0.5mm, 0.75mm,1.0mm,1.5mm,2.0mm,3.0mm,4.0mm,5.0mm
2.Main Width:4m, 5m, 5.8m, 6.0m, 7m, 8m,10m
3.Main Length:50m/100m/150m/200m
4.Main Color: black, white, blue, green
5. Optional surface: Textured or Smooth surface.
6.Material:HDPE, LDPE,LLDPE,EVA
7. Certificate & Test: ISO, TRI, SGS
8. Quality Control: Third party test and factory lab test

How To Choose PE Liner Membrana Thickness?

PE Liner Membrana Application And Uses

1. Environmental Protection

• Landfill liners & caps

• Wastewater treatment lagoons

2. Mining & Energy

• Heap leach pads

• Oilfield fluid containment

3. Water Conservation

• Potable water reservoirs

• Irrigation canals

4. Industrial

• Secondary containment

• Evaporation ponds

5. Aquaculture

• Shrimp/fish farming ponds

• Brine containment

Pond Liner HDPE Geomembrane Professional Installation Tips:

Base Preparation:
Remove sharp rocks/roots
Add 5-10cm sand/geotextile cushion

Liner Placement:
Unroll in warm weather (>10°C)
Allow 1m overlap at edges

Anchoring:
Bury edges in 30cm anchor trench
Use river rocks for natural finish
