Foundation Reinforcement Fiberglass Biaxial Composite Mesh Geogrid 30-300kn Strength

Fiberglass Geogrid Mesh Biaxial Composite Geogrid With Geotextile Coated By Glue

Composite Geogrid is a high-performance geosynthetics composed of a variety of materials, mainly used for foundation reinforcement, soil stabilization and structural enhancement in civil engineering.

Main application areas

Civil Engineering

Roadbed reinforcement: used for soft foundation treatment of highways and railways to reduce settlement.

Retaining wall and slope protection: improve structural stability through reinforcement, such as reinforced earth retaining wall.

Water conservancy project

Dyke anti-seepage: used in combination with geomembrane to form an anti-seepage isolation layer.

Drainage system: used for river slope protection or filter layer around drainage pipes.

Special scenarios

Electromagnetic shielding structure: Carbon fiber composite grid can be used for electromagnetic wave scattering control in military or aerospace fields.

Environmental remediation: used as isolation material in landfills or contaminated sites.

Applying a layer of geotextile on fiberglass with adhesive, the fiberglass composite geotextile has both high tensile strength, low elongation characteristics, and also has the performance of needle punched nonwoven fabric. So, fiberglass composite geotextile can be used for reinforcement, isolation and protection, and has a three-dimensional overall direction and level of good polysoil to abandon the role of water.

Manufacturing process and performance characteristics

Production process

Thermoplastic molding: forming a grid structure through high-temperature molding or ultrasonic welding, such as the rib welding process of steel-plastic grid.

Woven composite: weaving fiber materials (such as glass fiber) with polymer substrates and coating them with resin to enhance durability.

Key performance

High strength: tensile strength can reach 30-200 kN/m, which is better than single material grid.

Corrosion resistance: suitable for engineering scenarios in acidic and alkaline environments or long-term exposure.

Water permeability and reinforcement: allowing water to pass through while enhancing soil stability and preventing landslides.

Construction and standards

Construction points

When laying, ensure that the base is flat and free of sharp objects, the grid direction is perpendicular to the force direction, and the overlap width is ≥20 cm. Avoid mechanical rolling and direct contact with the grid, and cover the filler before compacting.

Quality standards

Our geocomposite gegogrid complied with international certifications such as ISO 9001 and ASTM, and the product must pass CE certification.
