High Strength 1.5mm Smooth HDPE Geomembrane Liner UV Resistance For Landfill Cover

Name: High Strength 1.5mm Smooth HDPE Geomembrane Liner UV Resistance For Landfill Cover
Brand: Dengwanyi Co., Ltd
SKU: HDPE LDPE LLDPE
Price: 0.30 USD
Availability: InStock

Brand Name:	SZ
Model Number:	HDPE LDPE LLDPE
MOQ:	30000 square meters
Price:	$0.3-$2.0/SQM
Payment Terms:	T/T,L/C
Supply Ability:	100 Tons per day

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO

Product Name:

HDPE Geomembrane

Thickness:

1.5mm

Application:

Landfill Cover

Function:

High Strength UV Resistance

Material:

HDPE LDPE LLDPE

Type:

Smooth Or Textured

Length:

50m-100m

Width:

1m-8m

Packaging Details:

Packed in woven bag or your requirements

Supply Ability:

100 Tons per day

Highlight:

HDPE Geomembrane Liner UV Resistance

1.5mm Smooth HDPE Geomembrane

HDPE Geomembrane For Landfill Cover

Product Description

High Strength UV Resistance 1.5mm Smooth Side HDPE Geomembrane Liner For Landfill Cover

Yixing Shenzhou 1.5mm HDPE geomembrane offers maximum durability for critical containment projects where superior strength and longevity are required. The thickest standard grade available, it provides unmatched protection against leaks and environmental contamination.

Yixing Shenzhou HDPE Geomembrane Key Advantages:

Industrial Strength: Withstands heavy equipment and sharp substrates

Versatile Performance: -60°C to +80°C operational range

Custom Sizes: Up to 8m wide × 100m long panels

Third-Party Tested: Include certified test reports

High Strength 1.5mm Smooth HDPE Geomembrane Liner UV Resistance For Landfill Cover 0

High Strength 1.5mm Smooth HDPE Geomembrane Liner UV Resistance For Landfill Cover 1

Item	Smooth Geomembrane Technical Data
Thickness mm	0.30	0.50	0.75	1.00	1.25	1.50	2.00	2.50	3.00
Density g/cm3	>=0.940
Tensile yield strength(TD/MD)	≥4	≥7	≥10	≥13	≥16	≥20	≥26	≥33	≥40
Tensile Strength at Break(TD/MD)	≥6	≥10	≥15	≥20	≥25	≥30	≥40	≥50	≥60
Elongation at Yield(TD/MD)	_	_	_	≥11
Puncture Strength(N)	≥72	≥120	≥180	≥240	≥300	≥360	≥480	≥600	≥720
Elongation (TD/MD)	≥600
Oxidation Induction Time(min)	≥60
Water vapor permeability coefficient ( gcm/(cms*Pa))	≤1.0x10-13
Dimensional Stability	±2.0

Pond Liner HDPE Geomembrane Professional Installation Tips:

The geomembrane can not be dragged and pull to avoid hu ing by sharp objects during carrying.

1. It should be extended from the bottom toward the top, can not tightly pull, it should keep 1.5% margins for local stretching. To view actual conditions, the laying sequence from top to bottom is adopted for the slope.

2. Two adjacent geomembrane's joints in the machine direction should not be on a levelline, should be staggered over 1 m. The overlap should be over 20cm.

3. The joints in the machine direction should be over 1.5m apa from the foot of dam, turn, should be located at the plane.

4. Laying order: first slope then the bottom of site

5. The direction of extened geomembrane should be basically paraliel with the line of maximum slope when laying the slope.

High Strength 1.5mm Smooth HDPE Geomembrane Liner UV Resistance For Landfill Cover 2
