High Strength Long Fiberglass Geogrids Self Adhensive Type For Platforms And Walkways

Brand Name:	SZ
Model Number:	FG
MOQ:	10,000 Square Meter
Price:	$0.3-$2.0/SQM
Payment Terms:	L/C,T/T
Supply Ability:	100,000 Square Meters per Week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO,CE

Product Name:

Asphalt Fiberglass Geogrid

Application:

Platforms And Walkways

Function:

High Strength Long Durable

Material:

Fiberglass Yarn

Coating:

Bitumen & Asphalt Geogrid

Tensile Strength:

50kN/m-300kN/m

Elongation Rate:

<=4%

Length*Width:

3.95*50M

Length:

50m-100m

Mesh Size:

25.4*25.4mm 12.5*12.5 50.8*50.8

Packaging Details:

By roll, paper pipe + black PE shrinkage membrane + woven bag ( waterproof & UV resistance)

Supply Ability:

100,000 Square Meters per Week

Highlight:

High Strength Long Fiberglass Geogrids

Fiberglass Geogrids Self Adhensive Type

Long Fiberglass Geogrids For Platforms

Product Description

High Strength Long Durable Fiberglass Geogrid For Platforms And Walkways

Highlights:
○ Reduces/Prevent Reflective Cracking
○ High Modulus Fiberglass Grid
○ Bituminous Coating Which Enhances Pavement life
○ Self Adhensive type - easy installation to save labour cost

Use & Purposes:
○ New road building with Asphalt Reinforcement Grid
○ Repair of Asphalt Pavement
○ Maintenance of Pavement
○ Rehabilitation of Pavement and road.

High Strength Long Fiberglass Geogrids Self Adhensive Type For Platforms And Walkways 1

Asphalt Fiberglass Geogrid :

Fiberglass geogrid technological standard(GB/T 21825-2008)
specification		FG30×30	FG50×50	FG 60×60	FG 80×80	FG 100×100	FG 120×120	FG 150×150
Mesh center distance(mm)	MD	25.4±3.8 , 12.7±3.8
Mesh center distance(mm)	CMD	25.4±3.8 , 12.7±3.8
breaking strength(kn/m)	MD	30	50	60	80	100	120	150
breaking strength(kn/m)	CMD	30	50	60	80	100	120	150
Breaking Elongation(%)	MD	4	4	4	4	4	4	4
Breaking Elongation(%)	CMD	4	4	4	4	4	4	4
Width(m)		1m-6m	1m-6m	1m-6m	1m-6m	1m-6m	1m-6m	1m-6m

High Strength Long Fiberglass Geogrids Self Adhensive Type For Platforms And Walkways 3

Asphalt Fiberglass Geogrid Professional Installation Guide :
Surface Preparation:
Mill existing pavement as needed
Apply polymer-modified tack coat (0.6-0.8 kg/m²)

Geogrid Placement:
Unroll with machine direction perpendicular to traffic flow
Minimum 300mm side overlaps, 500mm end overlaps

Asphalt Placement:

Minimum 75mm overlay thickness recommended
Maintain ≥150°C mix temperature during placement
