Slope Protection PE HDPE Geogrid 38x38 50X50mm Mesh 20-200KN/M Tensile Strength

Name: Slope Protection PE HDPE Geogrid 38x38 50X50mm Mesh 20-200KN/M Tensile Strength
Brand: Dengwanyi Co., Ltd
SKU: Hdpe Plastic Geogrid
Price: 0.30 USD
Availability: InStock

Brand Name:	SZ
Model Number:	Hdpe Plastic Geogrid
MOQ:	100,00sqm
Price:	$0.3-$2.0/SQM
Payment Terms:	L/C,D/A,T/T,Western Union,MoneyGram
Supply Ability:	20000 Square Meter per day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO/CE

Product Name:

HDPE Plastic Geogrid

Material:

HDPE

Tensile Strength:

20-200KN/M

Application:

Soil Reinforcement, Slope Stabilization, Retaining Walls, Road Construction

Roll Length:

50 M - 100 M

Roll Width:

1 M - 6 M

Color:

Black

Mesh Size:

38x38, 50X50mm

Packaging Details:

IN DUDE. OR CUSTOMIZED.

Supply Ability:

20000 Square Meter per day

Highlight:

Slope Protection HDPE Geogrid

50X50mm Mesh HDPE Geogrid

38x38mm Mesh HDPE Geogrid

Product Description

Slope Protection PE HDPE Geogrid Reinforcement for Soil Stabilization

Description:

HDPE (High-Density Polyethylene) Plastic Geogrids are engineered polymer grids designed for superior soil stabilization, slope reinforcement, and load distribution in civil engineering projects. Manufactured from virgin HDPE resin with UV stabilizers, these geogrids provide exceptional tensile strength and long-term durability in harsh environmental conditions.

Slope Protection PE HDPE Geogrid 38x38 50X50mm Mesh 20-200KN/M Tensile Strength 0

Key Advantages:

Ultra-High Strength (20-200kN/m tensile strength)
Chemical & Corrosion Resistant (HDPE material)
50+ Year Design Life (UV stabilized)
Cost-Effective vs. traditional concrete solutions

Technical Specifications:

Parameter	Uniaxial Geogrid	Biaxial Geogrid
Tensile Strength	20-200 kN/m (MD)	15-50 kN/m (MD/CD)
Aperture Size	25-150mm	15-100mm
Roll Dimensions	2-6m width x 50-100m	2-5m width x 50m
Temperature Range	-60°C to +80°C	-60°C to +80°C

Slope Protection PE HDPE Geogrid 38x38 50X50mm Mesh 20-200KN/M Tensile Strength 1

Project Applications

Road/Railway Construction
Base reinforcement for soft subgrades
Retaining Walls
Reduces required backfill material by 40%
Slope Stabilization
Prevents erosion on 70°+ slopes
Landfill Systems
Leachate collection layer reinforcement

#HDPE geogrid manufacturer #plastic geogrid for road construction#high strength soil stabilization grid

Uniaxial Geogrid is mainly applied in highway, railway, slope protection projects, retaining wall, dam to strength land loading capacity and extend its service life. Features in reducing area, project cost and maintenance cost, convenient to construct.
