120KN HDPE Plastic Geogrid Mesh Reinforced Soil Retaining Walls Slope Stabilization

Name: 120KN HDPE Plastic Geogrid Mesh Reinforced Soil Retaining Walls Slope Stabilization
Brand: Dengwanyi Co., Ltd
SKU: Hdpe Plastic Geogrid
Price: 0.30 USD
Availability: InStock

Brand Name:	SZ
Model Number:	Hdpe Plastic Geogrid
MOQ:	10000sqm
Price:	$0.3-$2.0/SQM
Payment Terms:	L/C,D/A,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO/CE

Product Name:

120KN HDPE Plastic Geogrids

Application:

Soil Reinforcement, Slope Stabilization, Retaining Walls, Road Construction

Material:

High Density Polyethylene (HDPE)

Tensile Strength:

20-200KN/M

Chemical Resistance:

Excellent

Roll Length:

50 M - 100 M

Roll Width:

1 M - 6 M

Color:

Black

Highlight:

120KN Plastic Geogrid Mesh

Slope Stabilization Plastic Geogrid Mesh

Product Description

120KN HDPE Plastic Geogrids Reinforced Soil Retaining Walls Slope Stabilization

Description:

Yixing Shenzhou HDPE Plastic Geogrids are engineered from high-density polyethylene using advanced extrusion and stretching technology, creating molecularly oriented grids with exceptional strength-to-weight ratios for soil reinforcement applications.

Key Advantages:

Ultra-High Strength (20-200kN/m tensile strength)
Chemical & Corrosion Resistant (HDPE material)
50+ Year Design Life (UV stabilized)
Cost-Effective vs. traditional concrete solutions

120KN HDPE Plastic Geogrid Mesh Reinforced Soil Retaining Walls Slope Stabilization 0

Technical Specifications:

Parameter	Uniaxial Geogrid	Biaxial Geogrid
Tensile Strength	20-200 kN/m (MD)	15-50 kN/m (MD/CD)
Aperture Size	25-150mm	15-100mm
Roll Dimensions	2-6m width x 50-100m	2-5m width x 50m
Temperature Range	-60°C to +80°C	-60°C to +80°C

120KN HDPE Plastic Geogrid Mesh Reinforced Soil Retaining Walls Slope Stabilization 1

Applications :

1. Reinforced Soil Structures
Retaining walls (up to 30m height)

Steep slope stabilization (up to 70°)

2. Transportation Infrastructure
Road and railway embankments
Airport runways and taxiways

3. Mining & Industrial
Tailings dam reinforcement
Heavy-duty access roads

4. Coastal & Waterfront
Revetment protection
Breakwater foundations

5. Landfill Engineering
Liner system reinforcement
Final cover systems
