Thickness 2000 Microns Mining Industry HDPE Geomembrane Liner Waterproof Anti-Seepage Project

Name: Thickness 2000 Microns Mining Industry HDPE Geomembrane Liner Waterproof Anti-Seepage Project
Brand: Shenzhou Earth Working Material Co. Ltd
SKU: HDPE LDPE LLDPE
Price: 0.30 USD
Availability: InStock

Brand Name:	SZ
Model Number:	HDPE LDPE LLDPE
MOQ:	30000 square meters
Price:	$0.3-$2.0/SQM
Payment Terms:	T/T,L/C
Supply Ability:	100 Tons per day

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO

Product Name:

HDPE Geomembrane

Thickness:

2000 Microns

Application:

Mining

Function:

Anti-seepage Waterproof

Material:

HDPE LDPE LLDPE

Type:

Smooth Or Textured

Length:

50m-200m

Width:

1m-8m

Packaging Details:

Packed in woven bag or your requirements

Supply Ability:

100 Tons per day

Highlight:

Seepage Project HDPE Geomembrane Liner

Waterproof HDPE Geomembrane Liner

2000 Microns HDPE Geomembrane Liner

Product Description

Thickness 2000 Microns Mining Industry HDPE Geomembrane Liner Waterproof And Anti-Seepage Project

Yixing Shenzhou HDPE Geomembrane
HDPE Geomembranes are thin two or three-dimensional sheets with very low permeability. The polymers come from a chemical plant in the shape of granules. During further processing, the granules are melted and after extrusion, eventually followed by spinning, the semi-manufactured products get the shape of sheets. The additives can be used during melting before extrusion. These additives have the main purpose of improving the less favorable properties of the basic materials, especially the sensitivity for alterations. HDPE Smooth Geomembrane ( YIXING SHENZHOU) is a smooth high-density polyethylene (HDPE) geomembrane manufactured with the highest quality resin specifically formulated for flexible geomembrane. HDPE Smooth Geomembrane is the preferred product for lining projects requiring low permeability, chemical, and ultraviolet resistance properties, which makes them extremely cost-effective for many applications.

Thickness 2000 Microns Mining Industry HDPE Geomembrane Liner Waterproof Anti-Seepage Project 0

No.	Properties	Test Method	Test Value
1	Thickness(mm)	ASTM D5199	0.50	0.75	1.00	1.25	1.50	2.00	2.50	3.00
2	Density (g/cm2)	ASTM D1505	0.939
3	Tensile Propeties
	Yield Strength(N/mm)	ASTM D6693	7	11	15	18	22	29	37	44
	Break Strength(N/mm)	ASTM D6693	13	20	27	33	40	53	67	80
	Yield Elongation %	Type IV	12
	Break Elongation %	Type IV	700
4	Tear Resistance/N	ASTM D1004	62	93	125	156	187	249	311	374
5	Puncture Resistance/N	ASTM D4833	160	240	320	400	480	640	800	960
6	Stress Crack resistance/hr	ASTM D5397 (App.)	300
7	Carbon Black
	Carbon Black Content %	ASTM D1603	2.0-3.0
	Carbon Black Dispersion	ASTM D5596	Carbon black dispersion(only near spherical agglomerates)for 10 different views 9 in categories 1 or 2 and 1 in category 3
8	Oxidative Induction Time(OIT)
	Standard OIT/min	ASTM D3895	100
	High Pressure OIT/min	ASTM D5885	400
9	Oven Aging at 85°C
	Standard OIT-% retained after 90 days	ASTM D3895	55
	High pressure OIT-% retained after 90 days	ASTM D5885	80
10	UV Resistance
	Standard OIT retained after 1600 hrs	ASTM D3895	50
	High pressure OIT retained after 1600 hrs	ASTM D5885	50
11	Low tempreture impact brittle property at -70°C	_	Pass
12	Permeability g·cm/(cm2)·Pa	_	≤1.0×10-13
13	Dimensional Stability/%	_	±2
